S600+ Instruction Manual
4-14 I/O Revised July-2017
Table 4-12. PRT/PRD Input Pin Connections for SKT-B
Pin
Function
4
PRT-CH1 I+
1
PRT-CH1 V+
21
PRT-CH1 V-
24
PRT-CH1 I-
5
PRT-CH2 I+
2
PRT-CH2 V+
22
PRT-CH2 V-
25
PRT-CH2 I-
6
PRT-CH3 I+
3
PRT-CH3 V+
23
PRT-CH3 V-
26
PRT-CH3 I-
4.1.10 Jumper Settings
The boldface entries in the Position column on Table 4-13 are the
default configuration settings. These may not apply to your specific
configuration. Do not change the jumpers settings unless told to do so
by the factory.
Note: Point-to-point communications for the I/O module require
jumper 2 to be ON. Multiplex (MUX) communications require
jumper 2 to be OFF.
