Emerson FloBoss S600+ User Manual

S600+ Instruction Manual
Revised July-2017 Startup 7-1
Chapter 7 – Startup
In This Chapter
7.1 Starting the S600+ ............................................................................ 7-1
7.2 Warm Start ........................................................................................ 7-1
7.3 Cold Start .......................................................................................... 7-2
7.3.1 Initiating a Cold Start ............................................................. 7-2
7.4 Startup Menu ..................................................................................... 7-3
7.4.1 Network Setup ....................................................................... 7-4
7.5 Messages .......................................................................................... 7-7
This chapter describes procedures for starting and restarting the S600+.
7.1 Starting the S600+
After you have wired the S600+ for power and connected it to external
devices, you activate it by energizing the external 24 Volts dc power
supply. When the S600+ first receives power, it automatically
performs an initialization sequence, including a self-test routine. The
S600+ displays the message RESETTING, and then automatically
performs a warm start.
7.2 Warm Start
A warm start does not affect the configuration memory (SRAM). The
S600+ continues operation, using the data stored in the configuration
memory just before the restart occurred. It also preserves any current
accumulated values.
During a warm start, the S600+ displays the message RESTARTING.
Following a successful warm start, the S600+ displays the Main menu,
which is the starting point for the display screens. (See the left side of
Figure 7-1; refer to Chapter 5, Front Panel, for more information on
navigating the display screens.)
If the S600+ cannot find a valid configuration, it does not perform a
warm start. Instead, it displays the Startup menu. (See the right side of
Figure 7-1 and refer to Section 7.3, Cold Start, for details.)
1* FLOW RATES
2* TOTALS
3* OPERATOR
4* PLANT I/O
5* SYSTEM SETTINGS
6* TECH/ENGINEER
8* CALCULATIONS
1* WARM START
2* COLD START
3* OPERATOR
4. NETWORK SETUP
5. CONFIG SELECTION
8* FACTORY SETUP
Figure 7-1. Main Menu and Startup Menu
