Emerson FloBoss S600+ User Manual

S600+ Instruction Manual
Revised July-2017 Chromatographs C-13
Stage
Description
5
Wait for RD and CV Poll
Reply
Wait up to the time-out period for the
2251 to respond. If no reply has been
received, then set the telemetry fail
alarm and set the stage to Idle.
If a reply has been received, then
proceed to Process the Analysis
Report.
6
Process the Analysis
Report
1. Reorder the raw telemetered mole
percentage into S600+ internal order
(as directed by the received
component codes, which run in
ascending values from 0).
2. If configured to do so, check low/high
and deduction limits
3. Normalise the reordered mole
percentage set.
4. If enabled (that is, non-zero values
entered), apply the additionals.
5. If enabled, apply the C6+ or C7+
splits.
6. Copy the processed mole
percentage set into the latest
processed set.
7. If enabled, perform critical alarm
checks on peak overflow, etc.
8. If enabled, perform non-critical alarm
check on ADC fails, etc.
9. If there are no limit, critical, or
deviation alarms, then mark the
analysis as good, copy the
processed mole percentage set into
the last good set, update the RD and
CV, and record the time.
C.5.2 Determining the Mole Percentage Set
This section details how the module selects the mole percentage set.
Keypad
Set Selected
Refer to Section C.3, Configuration Type: Keypad Mole Percentage
Set Only, for information on setting the keypad percentage set.
Chromatograph
Set Selected
The system uses the following logic to select a chromatograph set.
If the current report has no deviations or critical alarms, then
Copy the latest real RD into the Real RD.Chromat field.
Copy the latest real CV into the Real CV.Chromat field.
Copy the latest mole % set to the in-use mole % set.
Else
If the revert switch is set and a previous report is OK then
Copy the last good real RD to the Real RD.Chromat field.
Copy the latest real CV to the Real CV.Chromat field.
Copy the last good mole % to the in-use mole % set.
Else
Switch to using the keypad mole % set
Endif
