Emerson FloBoss S600+ User Manual

S600+ Instruction Manual
Revised July-2017 Front Panel 5-15
1* FLOW RATES
2* TOTALS
3* OPERATOR
4* PLANT I/O
5* SYSTEM SETTINGS
6* TECH/ENGINEER
8* CALCULATIONS
1. DISPLAY SETUP
2. CONTRAST
3. DATE & TIME
4. DISPLAY TEST
5. SECURITY
6* COMMUNICATIONS
7. USB
USB REPORT CTL
Status:
IDLE *
P204.1 <of 4>
Figure 5-15. USB Report Control Menu
Screens 3 and 4 in the USB report sequence (see Figure 5-16) enable
you define how the system presents report content (either as ASCII
text or as a CSV file) and whether reports are separate files or
combined.
USB REPORT PROGRESS
Value:
0 %
P204.2 <of 4>
USB REPORT FORMAT
Status:
TEXT
P204.3 <of 4>
USB REPORT COMBINE
Status:
NO
P204.4 <of 4>
Figure 5-16. USB Report Options
Note: Both of these options require you to enter a valid security code
before you can change the USB report defaults (text file and
separate reports).
4. Once you define the report parameters, return to the first screen
(USB Report Control) in the sequence.
Note: These settings become the defaults for all reports you
download to the USB flash drive until you change them.
5. Press CHNG.
6. Enter a valid security code. The USB Report Control menu
displays.
7. Select a report option. A confirmation screen displays.
USB REPORT PROGRESS
Value:
0 %
P204.2 <of 4>
1. ABORT
2. DUMP REPORTS
3. DUMP ALARMS
4. DUMP EVENTS
CONFIRM
SET TO:
DUMP REPORTS
1. YES
2. NO
Figure 5-17. Changing a Display Value
