S600+ Instruction Manual
8-4 Troubleshooting Revised July-2017
8.3.1 Reflash Firmware
Using this procedure, you can reprogram the S600+’s flash memory
with new values for the operating system components and the
application firmware.
Caution
Under no circumstances should you turn off the S600+ while it is erasing or
reprogramming the Flash memory. Doing so renders the S600+ unusable.
If this occurs, you must reload the configuration files and the correct version
of the operating system’s binary files.
To reprogram the flash memory:
1. Access the Startup menu on the front panel of the S600+ (refer to
Section 7.3.1).
2. Select REFLASH FIRMWARE from the Startup menu.
3. Press 1 to confirm the selection. The following message displays:
PERFORM CONFIG 600 FLASH COMMAND NOW
4. Access the Config Transfer program in the Config600 software,
select the required operating system .bin file, and click Send Now
to download it to the S600+.
Note: If you are unsure of the version required, consult with the
supplier who created your application.
5. The following message displays on the front panel:
RECEIVING BINARY FILE
Once the S600+ has successfully downloaded the file, the
following message displays on the front panel:
RECEIVED OK
Note: Do not proceed if the front panel displays the message
FLASH FAILED. Remove the power connector for 5
seconds and re-apply power. The S600+ redisplays the
startup menu. Begin again at step 1.
6. The S600+ then erases and reprograms the flash memory and
displays the message:
RESETTING - PLEASE WAIT
7. The S600+ then restarts. If the S600+ has not restarted after 30
seconds, remove the power connector, wait 5 seconds, and replace
the power connector. This returns you to the startup menu. Begin
again at step 1.
8.3.2 Send and Reflash the Config File
Using this procedure, you can download a new configuration file to the
S600+ and reprogram the S600+’s flash memory with those new
values.
