S600+ Instruction Manual
6-2 Webserver Access Revised July-2017
Figure 6-1. PCSetup Webserver Access
For further information on using this screen, refer to Chapter 7,
Advanced Setup Configuration, in the Config600 Software User
Manual (part D301220X412).
Once you complete this security level-access matrix, you can access
the S600+’s webserver over a TCP/IP connection.
Note: For firmware prior to version 06.05, webserver access is
available only through the NTWK1 port on the CPU module.
For firmware at or above version 06.05, webserver access is
available on both the NTWK1 and NTWK2 ports.
6.2 Accessing the S600+
While the S600+ web interface can support up to five concurrent
webserver sessions, it only allows one point of control at a time.
The S600+ gives control—the ability to change data—to the person
who first accesses the device, whether through the S600+ front panel
or through a TCP/IP connection. Anyone else who accesses the S600+,
regardless of access method, can only view data until the first user logs
off.
Control then passes to the next person with sufficient security who
requests that control. Since the S600+ automatically refreshed pages,
the page refresh acts as the request for control.
For this reason, ALWAYS use the Log Off option to exit the webserver
rather than just closing the browser session. Closing the browser
session may not completely relinquish control.
To access the S600+:
1. Connect to the S600+ using the standard communications port.
2. On a PC currently connected to the Internet, open the Windows
Internet Explorer browser (version 6 and greater).
