S600+ Instruction Manual
2-14 Installation Revised July-2017
8. Attach a medium ferrite clamp onto the wiring for COMs 5, 6, and
7 and a small ferrite clamp onto the Ethernet cable (see Figure 2-
16).
Figure 2-16. Clamps on CPU Module COM and Ethernet Connections
This completes the installation process and provides the S600+ with
EMC protection.
