S600+ Instruction Manual
C-18 Chromatographs Revised July-2017
Stage
Description
2
Poll for Status Data
Wait up to the time-out period for the unit
to respond and then (depending on the
data being polled for) either:
 Process the status report and, if
there is a new report, issue a new
poll to request the mole data and set
the next stage to be Poll for Mole
Percentages
 If there are no new reports, set the
next stage to Idle
If the poll response indicated a failure
then set the next stage to Idle.
3
Poll for Mole Percentages
Wait up to the time-out period for the unit
to respond and then (depending on the
data being polled for) either:
 Issue a new poll to request CV data
and set the next stage to Poll for
CV.
 If the poll response indicated a
failure then set the next stage to
Idle.
4
Poll for CV
Wait up to the time-out period for the unit
to respond and then (depending on the
data being polled for) either:
 Issue a new request to reset the
chromatograph and set the next
stage to Immediate Reset
 If the poll response indicated a
failure, then set the net stage to Idle.
5
Immediate Reset
Currently reserved stage; set the next
stage to Process Data
