Figure 7-4. Network Definition Menu
3. Select TCP/IP ADDRESS 1. The system prompts you to enter a
valid TCP/IP address.
4. Enter an address and press Enter.
Note: If the TCP/IP, gateway address, or subnet mask values are
correct, press CLEAR to accept the displayed value and
return to the Network Definition menu.
5. Select GATEWAY ADDRESS 1. The system prompts you to
enter a valid gateway address.
6. Enter an address and press Enter.
7. Select SUBNET MASK 1. The system prompts you to enter a
valid subnet mask.
8. Enter a valid subnet mask and press Enter.
9. Press 4, then 6 to return to the Startup menu.
If you specify a zero address for a Modbus slave configuration, the
S600+ configures the Modbus port using the address you enter here.
This is helpful when you load the same configuration file into multiple
S600+s on the same Modbus address: each S600+ then has a unique
node address.
To define the Modbus network address:
1. Select NETWORK SETUP from the Startup menu.
2. Select MODBUS ADDRESS. The Modbus Address screen
displays:
