Epson Artisan 800/Epson Stylus Photo PX800FW/TX800FW/Epson Artisan 700/Epson Stylus Photo PX700W/TX700W
Troubleshooting by Error Message
https://www.manualsbooks.com
Table 3-7. Check point for Paper jam error according to each phenomenon
Paper feeding operation is
performed normally, but the
paper is not fed inside the
printer.
1. Is Rear Paper Guide Assy correctly installed?
1. Install the Rear Paper Guide
Assy correctly.
4.2.4.9 " LD Roller " (p.142)
Lower ASF Paper
Guide Assy
1. Is Lower ASF Paper Guide Assy correctly Assy
installed?
1. Install the Lower ASF Paper
Guide Assy correctly.
4.2.4.7 " Lower ASF Paper
Guide Assy " (p.138)
2. Is the intermediate roller shaft correctly installed?
2. Install the intermediate roller
shaft correctly.
3. Is the surface of intermediate roller contaminated with
micro pearl paper dust or greasy dirt?
3. Clean the intermediate roller.
4. Does the flap of the Lower ASF Paper Guide Assy come
off?
4. Install the flap of the Lower ASF
Paper Guide correctly.
1. Is LD Roller shaft correctly installed?
1. Install the LD Roller shaft
correctly.
4.2.4.9 " LD Roller " (p.142)
2. Is the surface of LD Roller contaminated with micro
pearl paper dust or greasy dirt?
1. Is the Paper Guide Top Assy correctly installed?
1. Install the Paper Guide Top Assy
correctly.
4.2.2.13 " Paper Guide Top
Assy " (p.115)
Upper Paper Guide
L/R Assy
1. Is the Upper Paper Guide L/R Assy correctly installed?
1. Install the Upper Paper Guide L/
R Assy correctly.
4.2.4.19 " Upper Paper
Guide L/R / PE Sensor "
(p.161)
Multiple sheets of paper are
always fed at one time.
1. Is the Cassette Cork damaged or worn?
1. Replace the Cassette Cork with a
new one.
4.2.2.12 " Cassette Unit "
(p.114)
2. Is the rear end of the Cassette Assy damaged?
2. Replace the Cassette Unit with a
new one.
Sub Transmission
Cam Holder
1. Is the Sub Transmission Cam Holder correctly installed?
1. Install the Sub Transmission
Cam Holder correctly.
4.2.4.19 " Upper Paper
Guide L/R / PE Sensor "
(p.161)
To Next Page
