Ethernet Automatic Protection Switching
ExtremeWare XOS 11.3 Concepts Guide
410
State On a transit node, the command displays one of the following states:
• Idle—The EAPS domain has been enabled, but the configuration is
not complete.
• Links-Up—This EAPS domain is running, and both its ports are up
and in the forwarding state.
• Links-Down—This EAPS domain is running, but one or both of its
ports are down.
• Preforwarding—This EAPS domain is running, and both of its ports
are up, but one of them is in a temporary blocked state.
On a master node, the command displays one of the following states:
• Idle—The EAPS domain has been enabled, but the configuration is
not complete.
• Init—The EAPS domain has started but has not yet determined the
status of the ring. The secondary port is in a blocked state.
• Complete—The ring is in the complete state for this EAPS domain.
• Failed—There is a break in the ring for this EAPS domain.
• Pre-Init—The EAPS domain has started operation for Init state and
has sent a request to lower hardware layers to block the secondary
port. It is in transient state waiting for acknowledgement from
hardware layer indicating the operation is completed.
• Pre-Complete—The EAPS domain has started operation for
Complete state and has sent a request to lower hardware layers to
block the secondary port. It is in transient state waiting for
acknowledgement from the hardware layer indicating the operation
is completed.
• [Failtimer Expired]—When the failtimer expires and its action is set
to send-alert, this flag is set. This flag indicates there is a
misconfiguration or hardware problem in the EAPS ring. The EAPS
master node will continue to remain in COMPLETE or INIT state
with it’s secondary port blocking.
[Running: …] • Yes—This EAPS domain is running.
• No—This EAPS domain is not running.
Enabled Indicates whether EAPS is enabled on this domain:
• Y—EAPS is enabled on this domain.
• N—EAPS is not enabled.
Mode The configured EAPS mode for this switch: transit (T) or master (M).
Primary/Secondary port The port numbers assigned as the EAPS primary and secondary ports.
On the master node, the port distinction indicates which port is
blocked to avoid a loop.
Port status Indicates port status as one of the following states:
• Unknown—This EAPS domain is not running, so the port status has
not yet been determined.
• Up—The port is up and is forwarding data.
• Down—The port is down.
• Blocked—The port is up, but data is blocked from being forwarded.
Table 57: show eaps display fields (Continued)
Field Description
