Software Control: Entering Commands in Summary
C O N F I D E N T I A L – FEI Limited Rights Data3-56
Table 3-4
Function and Specific Key Short-cuts
Key (+ Key) Function
Esc stops the stage motion at that point
Note
During particular procedures, Home Stage for instance,
use the software Cancel or Stop button!
F1 shows documentation
Shift + F1 shows Image properties
(Shift +) F2 Starts Photo with an active beam
(in all displays with the same beam at once)
Ctrl + (Shift +) F2 starts / stops Active Preset Snapshot (from all displays at once)
(Ctrl+) F3 toggles Videoscope On / Off (in all displays)
Shift + F3 starts Home Stage procedure
(Ctrl +) F4 Starts / Stops electron (ion) imaging Snapshot from active display
Shift + F4 starts / stops Lens Alignment procedure
F5 toggles Single / Quad Image mode
Ctrl + F5 toggles Large Image Window mode
Shift + F5 toggles Center Cross show
F6 pauses / releases scanning
Shift + F6 toggles Alignment rectangle show
F7 switches Reduced Area On / Off
Ctrl + F7 starts Image Post Processing
F8 starts Degauss procedure
(Shift +) F9 starts Auto Contrast Brightness procedure (in all live displays)
F11 starts Auto Focus procedure
Ctrl + F11 starts Auto Stigmator procedure
Shift + F11 toggles Display Saturation function
(Shift +) F12 toggles Compucentric (Scan) Rotation tool
Ctrl + 0 – number moves stage to X=0, Y=0 – Center Position procedure
Ctrl + Shift + A starts / stops alternating of electron and ion imaging
Ctrl + B toggles Beam Blank function
Ctrl + E tilts stage to 0°
Ctrl + F sets Electron / Ion beam focus to eucentric WD (7 mm / 19 mm)
Ctrl + H sets Horizontal Field Width (HFW)
Ctrl + I tilts stage to 52°
Ctrl + K sets Spot mode conditions
Ctrl + M sets Full Frame scanning conditions
Ctrl + Shift + M starts movie recording
Ctrl + N toggles Sample Navigation On / Off
