F.3.1.1 [id]
The "id" blackidentifies the make and model
of
the osa. The Model 395 uses items
in this
black:,
but the Model395 does not send these items
ta
the OSO
as
commands. The
"id"
black
uses these commands:
version;
id;
make;
model.
version = number
The "number" permits the programmer
of
the OSO driver
ta
reference driver versions
(usually starting a 1.0). Version is not used by the Model 395.
For
example:
version "1.6" identifies the driver as version 1.6.
id =string
The
"id"
string identifies the
make
and
model
number
of
the
DSO
which will be
displayed on the DSO screen's DSO listing. The string can contain up to
15
characters
including spaces.
For
example:
id
= "LeCroy 94XX" places "LeCroy 94XX" in the Madel 395 DSO listing.
make = string
The
"make"
string
allows
the
DSO
driver
programmer
to
reference
the
make
or
manufacturer
of
the DSO. Make is not used
by
the Madel 395.
For example:
make
="LeCroy" identifies LeCroy
as
the manufacturer
of
the DSO.
model = string
The
"moder'
string allows the DSO driver programmer
ta
reference the actual model
of
the DSO used when writing the driver. Model
is
optional andnot used by the Model 395.
For example: "model
=9420" identifies the LeCroy
9420
as the
DSO
used when the
driver was written.
[id] Example
Surnmary:
[id]
version
=1.6
id
LeCroy 94XX
make
=LeCroy
model 9420
F.3.1.2 [setup n]
The "setup" black commands setup the DSO and Model 395. The
DSO
driver
me
can
contain up
ta
two setup blocks that are identified by
the
numbern
(1
or
2).
If
only one
"setup" block is used,
it
mustinc1ude a number [setup 1]. The "setup"
black
uses these
commands:
timeout
send
timeout=string
This string sets the GPffi handshake timeout
in
seconds. The "timeout" string allows
the
programmer to set the time the Model 395 wait for data from
the
DSO before
disconnecting or timing out. While there is no upper limit to the timeout, the practical
limit is
10
seconds.
For
example:
timeout
=
"OS'
sets
the
GPIB handshake timeout
ta
0.5 seconds.
F-4 osaUpload
