send=string
This string semIs commands to the DSO that define the DSO waveform transfer format.
Maximum string size is 256 ASCII characters.
To
send
a carriage return, use u\r;u
linefeed is "\n."
To determine the proper commands, consult the DSO manual for the GPffi or the SCPI
commands thatcontrol binary waveform transfer from the DSO to external devices. The
Model395 receives data
as
straightbinary data or
as
defined by the IEEE-488.2 Definite
Length Arbitrary Block Data format (paragraph 5.8) and expects the data in the format
defined by the [format] block commands.
For example: the Tektronix 2430 would use these commands:
send
==
"data encdg:rpbinary"
which selects the rightjustifiedpositive integer format.
The Gould 1624 would use these commands:
send
==
"WIND==O,
1023\n"
send
==
"BSLO\n"
send
==
"NB==BIN\n"
which selects infinite
length
binary transfer
of
1024 bytes. Note the
"\n"
linefeed is included.
F.3.1.3 [select
n]
The "select" block commands select the DSO waveform source. The DSO driver file
can contain
up
to 20 "select" blocks. Each "select" block is identified by the number
n
(1
through 20). Each "select" blockmust contain at least one display message and a
list
of
one
or
more commands.
If
only one "setup"
block
is
used,
it
must
include a
number [setup 1]. The "setup" block uses these commands:
display
send
display=string
This command is used by the Model 395 to identify the
DSO
waveform source. This
item is listed under the OSO setup screen. Each string can contain up to 15 characters
commands. The string will be displayed on the Model 395 screen.
For example: display
==
"CHANNEL 1" displays CHANNEL
Ion
the DSO setup screen.
send=string
This string sends commands to the
DSO
that define the waveform source. Maximum
string size is 256
Ascn
characters. To send a carriagereturn, use "\r;u linefeed is
U\n.
U
For example: send
==
"DATA
SOURCE:
CHI"
sends the
command
at
do
upload that
selects channel I as the waveform source.
[select] Example Summary:
[select
1]
display
==
"CHANNEL
l''
send
==
"DATA
SOURCE:
CHI"
Dsa
Upload
F-5
