Pinout Tables
MPC5200B Users Guide, Rev. 1
Freescale Semiconductor 2-69
Pin MEM_MA_11
Ball E20
logic 0 SDRAM Bus Memory Address 11
Pin MEM_MA_10
Ball B17
logic 0 SDRAM Bus Memory Address 10
Pin MEM_MA_9
Ball E19
logic 0 SDRAM Bus Memory Address 9
Pin MEM_MA_8
Ball D20
logic 0 SDRAM Bus Memory Address 8
Pin MEM_MA_7
Ball D19
logic 0 SDRAM Bus Memory Address 7
Pin MEM_MA_6
Ball C20
logic 0 SDRAM Bus Memory Address 6
Pin MEM_MA_5
Ball C19
logic 0 SDRAM Bus Memory Address 5
Pin MEM_MA_4
Ball B20
logic 0 SDRAM Bus Memory Address 4
Pin MEM_MA_3
Ball C16
logic 0 SDRAM Bus Memory Address 3
Pin MEM_MA_2
Ball B16
logic 0 SDRAM Bus Memory Address 2
Pin MEM_MA_1
Ball A16
logic 0 SDRAM Bus Memory Address 1
Pin MEM_MA_0
Ball C17
logic 0 SDRAM Bus Memory Address 0
Pin MEM_MDQ_31
Ball U18
hi - z SDRAM Bus Data 31
Pin MEM_MDQ_30
Ball T18
hi - z SDRAM Bus Data 30
Pin MEM_MDQ_29
Ball R18
hi - z SDRAM Bus Data 29
Pin MEM_MDQ_28
Ball R17
hi - z SDRAM Bus Data 28
Pin MEM_MDQ_27
Ball P18
hi - z SDRAM Bus Data 27
Pin MEM_MDQ_26
Ball
N18
hi - z SDRAM Bus Data 26
Pin MEM_MDQ_25
Ball N17
hi - z SDRAM Bus Data 25
Table 2-27. SDRAM Bus Pin Functions (continued)
PIN BALL NUMBER Function
Reset
Value
Description
