MPC5200B Users Guide, Rev. 1

2-70 Freescale Semiconductor

Pinout Tables

Pin MEM_MDQ_24

Ball M18

hi - z SDRAM Bus Data 24

Pin MEM_MDQ_23

Ball K18

hi - z SDRAM Bus Data 23

Pin MEM_MDQ_22

Ball J17

hi - z SDRAM Bus Data 22

Pin MEM_MDQ_21

Ball J18

hi - z SDRAM Bus Data 21

Pin MEM_MDQ_20

Ball H18

hi - z SDRAM Bus Data 20

Pin MEM_MDQ_19

Ball G18

hi - z SDRAM Bus Data 19

Pin MEM_MDQ_18

Ball G17

hi - z SDRAM Bus Data 18

Pin MEM_MDQ_17

Ball F18

hi - z SDRAM Bus Data 17

Pin MEM_MDQ_16

Ball E18

hi - z SDRAM Bus Data 16

Pin MEM_MDQ_15

Ball M20

hi - z SDRAM Bus Data 15

Pin MEM_MDQ_14

Ball M19

hi - z SDRAM Bus Data 14

Pin MEM_MDQ_13

Ball

L20

hi - z SDRAM Bus Data 13

Pin MEM_MDQ_12

Ball L19

hi - z SDRAM Bus Data 12

Pin MEM_MDQ_11

Ball K20

hi - z SDRAM Bus Data 11

Pin MEM_MDQ_10

Ball K19

hi - z SDRAM Bus Data 10

Pin MEM_MDQ_9

Ball J20

hi - z SDRAM Bus Data 9

Pin MEM_MDQ_8

Ball J19

hi - z SDRAM Bus Data 8

Pin MEM_MDQ_7

Ball P19

hi - z SDRAM Bus Data 7

Pin MEM_MDQ_6

Ball P20

hi - z SDRAM Bus Data 6

Table 2-27. SDRAM Bus Pin Functions (continued)

PIN BALL NUMBER Function

Reset

Value

Description
