Freescale Semiconductor MPC5200B - Page 116

Pinout Tables
MPC5200B Users Guide, Rev. 1
Freescale Semiconductor 2-71
Pin MEM_MDQ_5
Ball R19
hi - z SDRAM Bus Data 5
Pin MEM_MDQ_4
Ball R20
hi - z SDRAM Bus Data 4
Pin MEM_MDQ_3
Ball T19
hi - z SDRAM Bus Data 3
Pin MEM_MDQ_2
Ball T20
hi - z SDRAM Bus Data 2
Pin MEM_MDQ_1
Ball U19
hi - z SDRAM Bus Data 1
Pin MEM_MDQ_0
Ball U20
hi - z SDRAM Bus Data 0
Pin MEM_RDCLK
Ball not pinned out
clk SDRAM Bus Memory Read Clock
(not pinned out)
Table 2-28. JTAG and Test Pin Functions
PIN BALL NUMBER Function
Reset
Value
Description
Pin JTAG_TCK
Ball B04
JTAG Test Clock
Pin JTAG_TMS
Ball A04
JTAG Test Mode Select
Pin JTAG_TDI
Ball A03
JTAG Test Data In
Pin JTAG_TRST
Ball B03
JTAG Reset
Pin JTAG_TDO
Ball A02
JTAG Test Data Out
Pin TEST_MODE_0
Ball B02
Test Mode Select 0 (for production test)
NOTE: This pin requires a pull-down resistor.
Pin TEST_MODE_1
Ball A01
Test Mode Select 1 (for production test)
NOTE: This pin requires a pull-down resistor.
Pin TEST_SEL_0
Ball B01
Scan Enable (for production test), PLL_BYPASS -
input, CK_STOP - output
Pin TEST_SEL_1
Ball C03
ENID Input in Test Mode (for production test)
NOTE: This pin requires a pull-down resistor.
Table 2-27. SDRAM Bus Pin Functions (continued)
PIN BALL NUMBER Function
Reset
Value
Description
