Fuji Xerox Versant 80 Press

2 Product Overview
58
Product Overview
2
 HCF B1-S (optional), High Capacity Feeder C3-DS (optional)
1
2
3
5
7
8
8
9
1
2
3
5
4
4
6
6
HCF B1-S High Capacity Feeder C3-DS
No. Component Function
1 Ground fault interrupter Automatically turns the machine off when a current leakage is detected.
2 Tray 5 (Bypass) Used for loading non-standard paper that cannot be loaded in Trays 1 to 3,
6, and 7.
3 Tray 5 (Bypass) top cover Open this cover to clear paper jams.
4 Error lamp If a paper jam occurs, this lamp lights up.
5 Front door of the High
Capacity Feeder
Open this door to clear paper jams. This unit conveys paper supplied from
Tray 5 (Bypass), 6, and 7 to the machine.
6 Paper check window The remaining amount of paper can be confirmed.
7 Consumable storage space Store consumables and paper here.
8 Tray 6 Load paper here.
9 Tray 7 Load paper here.
