Fuji Xerox Versant 80 Press

2 Product Overview
62
Product Overview
2
 Squarefold Trimmer Module (optional)
12
3
4
5
6
7
8
No. Component Function
1 Left cover of the Trimmer
unit
Open this cover when clearing paper jams.
2 Right cover of the Trimmer
unit
Open this cover when clearing paper jams.
3 Ground fault interrupter Automatically shuts off electricity in the event of current leakage.
4 Booklet tray Outputs are delivered here when [Fold Only], [Fold & Staple], or [Booklet
Trimming / Pressing] is selected.
5 Squarefold setting button Use this button to adjust the amount of pressure applied to the spine of
booklets when the spine is flattened.
6 Error lamp If a paper jam occurs, the lamp of the jammed location lights up.
7 Trimmer waste container Collects scraps from the trimmer. Pull this container out when discarding the
scraps.
8 Booklet tray button Press this button to deliver booklets to retrieval position.
