Paper Jams
857
Problem Solving
22
When the HCF B1-S or the High Capacity Feeder C3-DS is installed
1) Open the front door of the High Capacity Feeder.
2 Open the bottom left door while gripping the
release handle.
3 Remove the jammed paper at the top.
Note • If paper is torn, check for any torn pieces of
paper inside the machine.
4 Remove the lower jammed paper if there is.
Note • If paper is torn, check for any torn pieces of
paper inside the machine.
5 Close the bottom left door.
Note • A message will be displayed and the machine will not operate if the bottom left door is even slightly
open.
6 When the following option is installed, perform the following.
When the HCF B1 is installed
1) Slowly return the HCF B1 to its original position.
When the HCF B1-S or the High Capacity Feeder C3-DS is installed
1) Close the front door of the High Capacity Feeder.
To Next Page
