Paper Jams
877
Problem Solving
22
4 Close the finisher right door.
Note • A message will be displayed and the machine will not operate if the finisher right door is even
slightly open.
Paper Jams at the Handle [3e] and the Knob [3c]
1
Make sure that the machine has stopped, and
open the finisher right door.
2 Move the handle [3e] (1) and turn the knob [3c]
to the right (2). Remove the jammed paper.
Note • If paper is torn, check for any torn pieces of
paper inside the machine.
• If you cannot see jammed paper, check
handle [1d] , and [3b]/[3d] as well.
• When the D4/D5 Folder Unit is installed,
check the handle [2a] as well.
3 Return the handle [3e] to its original position.
4 Close the finisher right door.
Note • A message will be displayed and the machine will not operate if the finisher right door is even
slightly open.
Paper Jams at the Handle [3g] and the Knob [3f]
1
Make sure that the machine has stopped, and
open the finisher right door.
To Next Page
