CHAPTER 10 WILD REGISTER FUNCTION
10.4 Registers
10.4 Registers
This section describes the registers of the wild register function.
■ Wild Register Number
A wild register number is assigned to each wild register address setting register (WRAR) and
each wild register data setting register (WRDR).
Table 10.4-1 List of Hardware/software Watchdog Timer Register
Register
abbreviation
Register name Reference
WRDR0 Wild register data setting register 0 10.4.1
WRDR1 Wild register data setting register 1 10.4.1
WRDR2 Wild register data setting register 2 10.4.1
WRAR0 Wild register address setting register 0 10.4.2
WRAR1 Wild register address setting register 1 10.4.2
WRAR2 Wild register address setting register 2 10.4.2
WREN Wild register address compare enable register 10.4.3
WROR Wild register data test setting register 10.4.4
Table 10.4-2 Wild Register Numbers Corresponding to Wild Register Address Setting Registers
and Wild Register Data Setting Registers
Wild register
number
Wild register address setting register
(WRAR)
Wild register data setting register
(WRDR)
0 WRAR0 WRDR0
1 WRAR1 WRDR1
2 WRAR2 WRDR2
