Fujitsu 8FX User Manual

MB95630H Series
MN702-00009-2v0-E FUJITSU SEMICONDUCTOR LIMITED 329
CHAPTER 18 8/16-BIT PPG
18.7 Registers
18.7.6 8/16-bit PPG Output Reverse Register (REVC)
The 8/16-bit PPG output reverse register (REVC) reverses the PPG output
including the initial level.
■ Register Configuration
■ Register Functions
[bit7:6] Undefined bits
Their read values are always "0". Writing values to these bits has no effect on operation.
[bit5] REV21: PPG timer 21 (ch. 2) output level reverse bit
This bit selects the output level of PPG timer 21 (ch. 2).
[bit4] REV20: PPG timer 20 (ch. 2) output level reverse bit
This bit selects the output level of PPG timer 20 (ch. 2).
[bit3] REV11: PPG timer 11 (ch. 1) output level reverse bit
This bit selects the output level of PPG timer 11 (ch. 1).
[bit2] REV10: PPG timer 10 (ch. 1) output level reverse bit
This bit selects the output level of PPG timer 10 (ch. 1).
bit 7 6 5 4 3 2 1 0
Field — — REV21* REV20* REV11* REV10* REV01 REV00
Attribute — — R/W R/W R/W R/W R/W R/W
Initial value 0 0 0 0 0 0 0 0
*: Since the number of channels of the 8/16-bit PPG varies among products, these bits may become undefined bits on certain
products. For details, refer to the device data sheet.
bit5 Details
Writing "0" Selects normal polarity.
Writing "1" Selects reverse polarity.
bit4 Details
Writing "0" Selects normal polarity.
Writing "1" Selects reverse polarity.
bit3 Details
Writing "0" Selects normal polarity.
Writing "1" Selects reverse polarity.
bit2 Details
Writing "0" Selects normal polarity.
Writing "1" Selects reverse polarity.
