Fujitsu 8FX User Manual

MB95630H Series
130 FUJITSU SEMICONDUCTOR LIMITED MN702-00009-2v0-E
CHAPTER 10 WILD REGISTER FUNCTION
10.4 Registers
10.4.2 Wild Register Address Setting Registers
(WRAR0 to WRAR2)
The wild register address setting registers (WRAR0 to WRAR2) set the address
to be amended by the wild register function.
■ Register Configuration
■ Register Functions
[bit15:0] RA[15:0]: Wild register address setting bits
These bits set the address to be amended by the wild register function.
The address to be assigned to amendment data is set to these bits. The address is to be specified according to
the wild register number corresponding to a wild register address setting register.
WRAR0
bit 15 14 13 12 11 10 9 8
Field RA15 RA14 RA13 RA12 RA11 RA10 RA9 RA8
Attribute R/W R/W R/W R/W R/W R/W R/W R/W
Initial value 0 0 0 0 0 0 0 0
bit 7 6 5 4 3 2 1 0
Field RA7 RA6 RA5 RA4 RA3 RA2 RA1 RA0
Attribute R/W R/W R/W R/W R/W R/W R/W R/W
Initial value 0 0 0 0 0 0 0 0
WRAR1
bit 15 14 13 12 11 10 9 8
Field RA15 RA14 RA13 RA12 RA11 RA10 RA9 RA8
Attribute R/W R/W R/W R/W R/W R/W R/W R/W
Initial value 0 0 0 0 0 0 0 0
bit 7 6 5 4 3 2 1 0
Field RA7 RA6 RA5 RA4 RA3 RA2 RA1 RA0
Attribute R/W R/W R/W R/W R/W R/W R/W R/W
Initial value 0 0 0 0 0 0 0 0
WRAR2
bit 15 14 13 12 11 10 9 8
Field RA15 RA14 RA13 RA12 RA11 RA10 RA9 RA8
Attribute R/W R/W R/W R/W R/W R/W R/W R/W
Initial value 0 0 0 0 0 0 0 0
bit 7 6 5 4 3 2 1 0
Field RA7 RA6 RA5 RA4 RA3 RA2 RA1 RA0
Attribute R/W R/W R/W R/W R/W R/W R/W R/W
Initial value 0 0 0 0 0 0 0 0
