Fujitsu 8FX User Manual

MB95630H Series
348 FUJITSU SEMICONDUCTOR LIMITED MN702-00009-2v0-E
CHAPTER 19 16-BIT PPG TIMER
19.7 Registers
19.7.4 16-bit PPG Status Control Register (Upper) ch. n
(PCNTHn)
The 16-bit PPG status control register (upper) ch. n enables or disables the 16-
bit PPG timer, and controls the software trigger, operating mode, operating
clock and output mask.
■ Register Configuration
■ Register Functions
[bit7] CNTE: Timer enable bit
This bit enables or stops the 16-bit PPG timer operation.
When "0" is written to this bit, the 16-bit PPG timer operation stops immediately and the PPGn output goes
to the initial level ("L" output if OSEL is "0"; "H" output if OSEL is "1").
When "1" is written to this bit, the 16-bit PPG timer operation is enabled and the 16-bit PPG timer goes to
standby to wait for a trigger.
[bit6] STRG: Software trigger bit
This bit starts the 16-bit PPG timer by software.
With the CNTE bit set to "1", writing "1" to the STRG bit starts the 16-bit PPG timer.
[bit5] MDSE: Mode select bit
This bit selects the operating mode of the 16-bit PPG timer.
Note: While the 16-bit PPG timer is in operation, modifying the setting of this bit is prohibited.
bit 7 6 5 4 3 2 1 0
Field CNTE STRG MDSE RTRG CKS2 CKS1 CKS0 PGMS
Attribute R/W W R/W R/W R/W R/W R/W R/W
Initial value 0 0 0 0 0 0 0 0
bit7 Details
Writing "0" Stops the 16-bit PPG timer operation.
Writing "1" Enables the 16-bit PPG timer operation.
bit6 Details
Read access The read value is always "0".
Writing "0" Has no effect on operation.
Writing "1" Generates a software trigger.
bit5 Details
Writing "0" PWM mode
Writing "1" One-shot mode
