Fujitsu 8FX User Manual

MB95630H Series
446 FUJITSU SEMICONDUCTOR LIMITED MN702-00009-2v0-E
CHAPTER 21 MULTI-PULSE GENERATOR
21.6 Registers
21.6.7 16-bit MPG Timer Buffer Register (Upper/Lower)
(TMBUR/TMBLR)
The timer buffer register (upper/lower) (TMBUR/TMBLR) consists of two 8-bit
registers used to read the counter value of 16-bit timer.
The 16-bit MPG timer buffer register (upper) (TMBUR) and the 16-bit MPG timer buffer
register (lower) (TMBLR) store the counter value of the 16-bit timer at the point at which a
write timing trigger or a position detection trigger is generated. The counter is cleared to
"0x0000" upon the generation of the trigger.
Always use one of the following methods to access this register.
• Use the "MOVW" instruction (use a 16-bit access instruction to read the TMBUR register
address).
• Use the "MOV" instruction to read or write TMBUR first and then TMBLR.
■ Register Configuration
TMBUR
bit 7 6 5 4 3 2 1 0
Field T15 T14 T13 T12 T11 T10 T09 T08
Attribute R R R R R R R R
Initial value X X X X X X X X
TMBLR
bit 7 6 5 4 3 2 1 0
Field T07 T06 T05 T04 T03 T02 T01 T00
Attribute R R R R R R R R
Initial value X X X X X X X X
