Fujitsu 8FX User Manual

MB95630H Series
426 FUJITSU SEMICONDUCTOR LIMITED MN702-00009-2v0-E
CHAPTER 21 MULTI-PULSE GENERATOR
21.6 Registers
21.6 Registers
This section describes the registers of the multi-pulse generator.
Table 21.6-1 List of Multi-pulse Generator Registers
Register
abbreviation
Register name Reference
OPCUR 16-bit MPG output control register (upper) 21.6.1
OPCLR 16-bit MPG output control register (lower) 21.6.2
OPDUR 16-bit MPG output data register (upper) 21.6.3.1
OPDLR 16-bit MPG output data register (lower) 21.6.3.2
OPDBRHx 16-bit MPG output data buffer register (upper) 21.6.4.1
OPDBRLx 16-bit MPG output data buffer register (lower) 21.6.4.2
IPCUR 16-bit MPG input control register (upper) 21.6.5.1
IPCLR 16-bit MPG input control register (lower) 21.6.5.2
CPCUR 16-bit MPG compare clear register (upper) 21.6.6
CPCLR 16-bit MPG compare clear register (lower) 21.6.6
TMBUR 16-bit MPG timer buffer register (upper) 21.6.7
TMBLR 16-bit MPG timer buffer register (lower) 21.6.7
TCSR 16-bit MPG timer control status register 21.6.8
NCCR 16-bit MPG noise cancellation control register 21.6.9
