Fujitsu 8FX User Manual

MB95630H Series
434 FUJITSU SEMICONDUCTOR LIMITED MN702-00009-2v0-E
CHAPTER 21 MULTI-PULSE GENERATOR
21.6 Registers
21.6.3.2 16-bit MPG Output Data Register (Lower)
(OPDLR)
The 16-bit MPG output data register (lower) (OPDLR) indicates the waveform to
be output to the OPT3 to OPT0 pins.
■ Register Configuration
■ Register Functions
[bit7:6] OP3[1:0]: OPT3 output waveform bits
These bits indicate the output waveform to the OPT3 pin.
[bit5:4] OP2[1:0]
: OPT2 output waveform bits
These bits indicate the output waveform to the OPT2 pin.
[bit3:2] OP1[1:0]
: OPT1 output waveform bits
These bits indicate the output waveform to the OPT1 pin.
[bit1:0] OP0[1:0]
: OPT0 output waveform bits
These bits indicate the output waveform to the OPT0 pin.
bit 7 6 5 4 3 2 1 0
Field OP31 OP30 OP21 OP20 OP11 OP10 OP01 OP00
Attribute R R R R R R R R
Initial value X X X X X X X X
bit7:6 Details
Reading "00" Indicates that "L" level is output to the OPT3 pin.
Reading "01" Indicates that the output of the PPG timer is output to the OPT3 pin.
Reading "10" Indicates that the inverted output is output to the OPT3 pin.
Reading "11" Indicates that "H" level is output to the OPT3 pin.
bit5:4 Details
Reading "00" Indicates that "L" level is output to the OPT2 pin.
Reading "01" Indicates that the output of the PPG timer is output to the OPT2 pin.
Reading "10" Indicates that the inverted output is output to the OPT2 pin.
Reading "11" Indicates that "H" level is output to the OPT2 pin.
bit3:2 Details
Reading "00" Indicates that "L" level is output to the OPT1 pin.
Reading "01" Indicates that the output of the PPG timer is output to the OPT1 pin.
Reading "10" Indicates that the inverted output is output to the OPT1 pin.
Reading "11" Indicates that "H" level is output to the OPT1 pin.
bit1:0 Details
Reading "00" Indicates that "L" level is output to the OPT0 pin.
Reading "01" Indicates that the output of the PPG timer is output to the OPT0 pin.
Reading "10" Indicates that the inverted output is output to the OPT0 pin.
Reading "11" Indicates that "H" level is output to the OPT0 pin.
