MB95630H Series
538 FUJITSU SEMICONDUCTOR LIMITED MN702-00009-2v0-E
CHAPTER 26 DUAL OPERATION FLASH MEMORY
26.2 Sector/Bank Configuration
26.2 Sector/Bank Configuration
This section shows the sector/bank configuration of the Flash memory.
Sector/Bank Configuration of Dual Operation Flash Memory
Figure 26.2-1 shows the sector configuration of the Dual operation Flash memory. The upper
and lower addresses of each sector are shown in the figure.
Bank configuration
The lower bank of the Flash memory is SA0 and SA1 and the upper bank SA2.
Figure 26.2-1 Sector/Bank Configuration of Dual Operation Flash Memory
Flash memory
(8 Kbyte)
Flash memory
(12 Kbyte)
Flash memory
(20 Kbyte)
Flash memory
(36 Kbyte)
CPU
address
SA0: 2 Kbyte
Lower
bank
SA0: 2 Kbyte
Lower
bank
SA0: 2 Kbyte
Lower
bank
SA0: 2 Kbyte
Lower
bank
0x1000
0x17FF
SA1: 2 Kbyte SA1: 2 Kbyte SA1: 2 Kbyte SA1: 2 Kbyte
0x1800
0x1FFF
-
-
-
-
0x2000
0x7FFF
SA2: 32 Kbyte
Upper
bank
0x8000
0xBFFF
SA2: 16 Kbyte
Upper
bank
0xC000
0xDFFF
SA2: 8 Kbyte
Upper
bank
0xE000
0xEFFF
SA2: 4 Kbyte
Upper
bank
0xF000
0xFFFF
