Fujitsu 8FX User Manual

MB95630H Series
138 FUJITSU SEMICONDUCTOR LIMITED MN702-00009-2v0-E
CHAPTER 11 8/16-BIT COMPOSITE TIMER
11.2 Configuration
11.2 Configuration
The 8/16-bit composite timer consists of the following blocks:
• 8-bit counter
• 8-bit comparator (including a temporary latch)
• 8/16-bit composite timer data register (Tn0DR/Tn1DR)
• 8/16-bit composite timer status control register 0 (Tn0CR0/Tn1CR0)
• 8/16-bit composite timer status control register 1 (Tn0CR1/Tn1CR1)
• 8/16-bit composite timer timer mode control register (TMCRn)
• Output controller
• Control logic
• Count clock selector
• Edge detector
• Noise filter
The number of pins and that of channels of the 8/16-bit composite timer vary among products.
For details, refer to the device data sheet.
In this chapter, "n" in a pin name and a register abbreviation represents the channel number.
For details of pin names, register names and register abbreviations of a product, refer to the
device data sheet.
