MB95630H Series
346 FUJITSU SEMICONDUCTOR LIMITED MN702-00009-2v0-E
CHAPTER 19 16-BIT PPG TIMER
19.7 Registers
19.7.2 16-bit PPG Cycle Setting Buffer Register
(Upper/ Lower) ch. n (PCSRHn/PCSRLn)
The 16-bit PPG cycle setting buffer registers ch. n are used to set the cycle for
the output pulses generated by the PPG.
â– Register Configuration
â– Register Functions
These registers form a 16-bit register which sets the period for the output pulses generated by
the PPG. The values set in these registers are loaded to the downcounter.
When writing to these registers, always use one of the following procedures.
• Use the "MOVW" instruction (use a 16-bit access instruction to write to the PCSRHn
register address).
• Use the "MOV" instruction and write to PCSRHn first and then PCSRLn.
If a downcounter load occurs after writing data to PCSRHn (but before writing data to
PCSRLn), the previous valid PCSRHn/PCSRLn value will be loaded to the downcounter. If
the PCSRHn/PCSRLn value is modified during counting, the modified value will become
effective from the next load of the downcounter.
• Do not set PCSRHn and PCSRLn to "0x00", or PCSRHn to "0x01" and PCSRLn to "0x01".
Note:
If the downcounter load occurs after the "MOV" instruction is used to write data to
PCSRLn before PCSRHn, the previous valid PCSRHn value and newly written PCSRLn
value are loaded to the downcounter. It should be noted that as a result, the correct
period cannot be set.
PCSRHn
bit 7 6 5 4 3 2 1 0
Field CS15 CS14 CS13 CS12 CS11 CS10 CS09 CS08
Attribute R/W R/W R/W R/W R/W R/W R/W R/W
Initial value 1 1 1 1 1 1 1 1
PCSRLn
bit 7 6 5 4 3 2 1 0
Field CS07 CS06 CS05 CS04 CS03 CS02 CS01 CS00
Attribute R/W R/W R/W R/W R/W R/W R/W R/W
Initial value 1 1 1 1 1 1 1 1
