CHAPTER 23 UART/SIO DEDICATED BAUD RATE GENERATOR

23.2 Channel

This section describes the channel of the UART/SIO dedicated baud rate

generator.

■ Channel of UART/SIO Dedicated Baud Rate Generator

Table 23.2-1 shows the registers of the UART/SIO dedicated baud rate generator.

Table 23.2-1 Registers of Dedicated Baud Rate Generator

abbreviation

Corresponding register (Name in this manual)

PSSRn UART/SIO dedicated baud rate generator prescaler select register ch. n

BRSRn UART/SIO dedicated baud rate generator baud rate setting register ch. n
