Fujitsu 8FX User Manual

MB95630H Series
132 FUJITSU SEMICONDUCTOR LIMITED MN702-00009-2v0-E
CHAPTER 10 WILD REGISTER FUNCTION
10.4 Registers
10.4.4 Wild Register Data Test Setting Register (WROR)
The wild register data test setting register (WROR) enables or disables data
reading from the corresponding wild register data setting register (WRDR0 to
WRDR2).
■ Register Configuration
■ Register Functions
[bit7:6] Undefined bits
Their read values are always "0". Writing values to these bits has no effect on operation.
[bit5:3] Reserved bits
Always set these bits to "0".
[bit2:0] DRR[2:0]: Wild register data test setting bits
These bits enable or disable the normal reading from the corresponding data setting register of the wild
register.
• DRR0 corresponds to wild register number 0.
• DRR1 corresponds to wild register number 1.
• DRR2 corresponds to wild register number 2.
bit 7 6 5 4 3 2 1 0
Field — — Reserved Reserved Reserved DRR2 DRR1 DRR0
Attribute — — W W W R/W R/W R/W
Initial value 0 0 0 0 0 0 0 0
bit2/bit1/bit0 Details
Writing "0" Disables reading from the wild register data setting register.
Writing "1" Enables reading from the wild register data setting register.
