Fujitsu 8FX User Manual

MB95630H Series
MN702-00009-2v0-E FUJITSU SEMICONDUCTOR LIMITED 129
CHAPTER 10 WILD REGISTER FUNCTION
10.4 Registers
10.4.1 Wild Register Data Setting Registers
(WRDR0 to WRDR2)
The wild register data setting registers (WRDR0 to WRDR2) use the wild
register function to specify the data to be amended.
■ Register Configuration
■ Register Functions
[bit7:0] RD[7:0]: Wild register data setting bits
These bits specify the data to be amended by the wild register function.
These bits are used to set the amendment data at the address assigned by the wild register address setting
register (WRAR). Data is valid at an address corresponding to one of the wild register numbers.
The read access to one of these bits is enabled only when the data test setting bit in the wild register data test
setting register (WROR) corresponding to the bit to be read is set to "1".
WRDR0
bit 7 6 5 4 3 2 1 0
Field RD7 RD6 RD5 RD4 RD3 RD2 RD1 RD0
Attribute R/W R/W R/W R/W R/W R/W R/W R/W
Initial value 0 0 0 0 0 0 0 0
WRDR1
bit 7 6 5 4 3 2 1 0
Field RD7 RD6 RD5 RD4 RD3 RD2 RD1 RD0
Attribute R/W R/W R/W R/W R/W R/W R/W R/W
Initial value 0 0 0 0 0 0 0 0
WRDR2
bit 7 6 5 4 3 2 1 0
Field RD7 RD6 RD5 RD4 RD3 RD2 RD1 RD0
Attribute R/W R/W R/W R/W R/W R/W R/W R/W
Initial value 0 0 0 0 0 0 0 0
