CHAPTER 24 I
2
C BUS INTERFACE
24.7 Registers
24.7 Registers
This section describes the registers of the I
2
C bus interface.
Table 24.7-1 List of I
2
C Bus Interface Registers
Register
abbreviation
Register name Reference
IBCR0n
I
2
C bus control register 0 ch. n
24.7.1
IBCR1n
I
2
C bus control register 1 ch. n
24.7.2
IBSRn
I
2
C bus status register ch. n
24.7.3
IDDRn
I
2
C data register ch. n
24.7.4
IAARn
I
2
C address register ch. n
24.7.5
ICCRn
I
2
C clock control register ch. n
24.7.6
