CHAPTER 21 MULTI-PULSE GENERATOR
21.6 Registers
[bit1:0] OP4[1:0]
: OPT4 output waveform bits
These bits indicate the output waveform to the OPT4 pin.
bit1:0 Details
Reading "00" Indicates that "L" level is output to the OPT4 pin.
Reading "01" Indicates that the output of the PPG timer is output to the OPT4 pin.
Reading "10" Indicates that the inverted output is output to the OPT4 pin.
Reading "11" Indicates that "H" level is output to the OPT4 pin.
