MB95630H Series
174 FUJITSU SEMICONDUCTOR LIMITED MN702-00009-2v0-E
CHAPTER 11 8/16-BIT COMPOSITE TIMER
11.15 Notes on Using 8/16-bit Composite
Timer
Figure 11.15-1 Operations of Counter in Standby Mode or in Pause
(Not Serving as PWM Timer)
Figure 11.15-2 Operations of Counter in Standby Mode or in Pause
(Serving as PWM Timer)
Counter value
0xFF
0x80
0x00
Tn0DR/Tn1DR data register value (0xFF)
Timer cycle
Time
IF bit
STA bit
IE bit
SLP bit
(STBC register)
STP bit
(STBC register)
Wake-up from stop mode by external interrupt
HO bit
Stop mode
Wake-up from sleep mode by interrupt
Operation reactivated
Operation halts
Delay of oscillation stabilization wait time
Interval time after wake-up
from stop mode (indeterminate)
Request ends
HO request
HO request ends
Operation resumes
Sleep mode
Cleared by program
Counter value
0xFF
0x00
Tn0DR/Tn1DR value (0xFF)
Time
STA bit
PWM timer output pin
(0xFF)
SLP bit
(STBC register)
STP bit
(STBC register)
Sleep mode
*
*: The PWM timer output maintains the value held before it enters the stop mode.
HO bit
Maintains the level prior to hold
Maintains the level prior to stop
Wake-up from stop mode by external interrupt
Wake-up from sleep mode by interrupt
Delay of oscillation stabilization wait time
