MB95630H Series
182 FUJITSU SEMICONDUCTOR LIMITED MN702-00009-2v0-E
CHAPTER 12 EXTERNAL INTERRUPT CIRCUIT
12.6 Operations and Setting Procedure
Example
■ Setting Procedure Example
Below is an example of procedure for setting the external interrupt circuit.
● Initial settings
1. Set the interrupt level. (ILR*)
2. Select the edge polarity. (EIC:SL0[1:0])
3. Enable interrupt requests. (EIC:EIE0 = 1)
*: For details of the interrupt level setting register (ILR), refer to "CHAPTER 5 INTERRUPTS" in this
hardware manual and "■ INTERRUPT SOURCE TABLE" in the device data sheet.
● Interrupt processing
1. Clear the interrupt request flag. (EIC:EIR0 = 0)
2. Process any interrupt.
Note:
An external interrupt input port shares the same pin with a general-purpose I/O port.
Therefore, when using the pin as an external interrupt input port, set the bit in the port
direction register (DDR) corresponding to that pin to "0" (input).
