CHAPTER 14 LIN-UART
14.6 Operations of LIN-UART and LIN-UART
Setting Procedure Example
● Communication procedure
Master/slave mode communication starts as the master CPU transmits address data. The
address data, which is the data chosen when the AD bit is set to "1", determines the slave CPU
that is to be the destination of the communication. A slave CPU uses a program to check
address data, and communicates with the master CPU when the address data matches the
address assigned to that slave CPU.
Figure 14.6-15 is a flow chart showing master/slave mode communication (multiprocessor
mode).
Table 14.6-4 Selection of Master/Slave Mode Communication Functions
Operating mode
Data Parity
Synchronous
method
Stop bit Bit direction
Master CPU Slave CPU
Address
transmission/
reception
Operating
mode 1
(Transmit/
receive AD
bit)
Operating
mode 1
(Transmit/
receive AD
bit)
AD = 1
+
7-bit or 8-bit address
None Asynchronous 1 bit or 2 bits
LSB first
or
MSB first
Data
transmission/
reception
AD = 0
+
7-bit or 8-bit data
