CHAPTER 19 16-BIT PPG TIMER
19.7 Registers
[bit3:2] IRS[1:0]: Interrupt type select bit
These bits select the interrupt source type for the 16-bit PPG timer.
[bit1] POEN: Output enable bit
This bit enables or disables the 16-bit PPG timer output pin output.
[bit0] OSEL: Output inversion bit
This bit selects the polarity of the 16-bit PPG timer output pin.
When "0" is written to this bit, the PPG output goes to "H" when "L" is output in the internal start and the
16-bit downcounter value matches the duty setting register value, and goes to "L" when a downcounter
borrow occurs (normal polarity).
When "1" is written to this bit, the 16-bit PPG timer output is inverted (inverted polarity).
bit3:2 Details
Writing "00" Trigger by input, software trigger, or retrigger
Writing "01" Counter borrow
Writing "10"
Rising edge of 16-bit PPG timer output in normal polarity, or falling edge of 16-bit PPG timer
output in inverted polarity
Writing "11"
Counter borrow, rising edge of 16-bit PPG timer output in normal polarity, or falling edge of 16-
bit PPG timer output in inverted polarity
bit1 Details
Writing "0" The 16-bit PPG timer output pin functions as a general-purpose I/O port.
Writing "1" The 16-bit PPG timer output pin functions as an output pin for the 16-bit PPG timer.
bit0 Details
Writing "0" Normal polarity
Writing "1" Inverted polarity
