CHAPTER 21 MULTI-PULSE GENERATOR
21.6 Registers
[bit4] OPE4: OPT4 output enable bit
This bit enables or disables OPT4 pin output.
[bit3] OPE3: OPT3 output enable bit
This bit enables or disables OPT3 pin output.
[bit2] OPE2: OPT2 output enable bit
This bit enables or disables OPT2 pin output.
[bit1] OPE1: OPT1 output enable bit
This bit enables or disables OPT1 pin output.
[bit0] OPE0: OPT0 output enable bit
This bit enables or disables OPT0 pin output.
bit4 Details
Writing "0" Disables OPT4 pin output.
Writing "1" Enables OPT4 pin output.
bit3 Details
Writing "0" Disables OPT3 pin output.
Writing "1" Enables OPT3 pin output.
bit2 Details
Writing "0" Disables OPT2 pin output.
Writing "1" Enables OPT2 pin output.
bit1 Details
Writing "0" Disables OPT1 pin output.
Writing "1" Enables OPT1 pin output.
bit0 Details
Writing "0" Disables OPT0 pin output.
Writing "1" Enables OPT0 pin output.
