Fujitsu 8FX User Manual

MB95630H Series
MN702-00009-2v0-E FUJITSU SEMICONDUCTOR LIMITED 437
CHAPTER 21 MULTI-PULSE GENERATOR
21.6 Registers
[bit1:0] OP4[1:0]
: OPT4 output waveform select bits
These bits select the output waveform to the OPT4 pin.
The waveform selected is to be output to the OPT4 pin after the data in the OPDBRHx/OPDBRLx specified
in the BNKF bit and RDA[2:0] bits is loaded to the OPDUR/OPDLR register.
bit1:0 Details
Writing "00" Selects "L" level as the waveform to be output to the OPT4 pin.
Writing "01" Selects the output of the PPG timer as the waveform to be output to the OPT4 pin.
Writing "10" Selects the inverted output as the waveform to be output to the OPT4 pin.
Writing "11" Selects "H" level as the waveform to be output to the OPT4 pin.
