CHAPTER 21 MULTI-PULSE GENERATOR
21.6 Registers
[bit3:1] CPD[2:0]: Compare bits
These bits are used to compare with the RDA[2:0] bits in the 16-bit MPG output data register (upper)
(OPCUR). When the value of the CPD[2:0] bits match the value of the RDA[2:0] bits, the compare interrupt
request flag bit (CPIF) is set to "1".
[bit0] CMPE: Position detection compare enable bit
This bit enables or disables the compare operation in position detection.
bit3:1 Details
Writing "000" If the RDA[2:0] bits are "000", a compare match occurs.
Writing "001" If the RDA[2:0] bits are "001", a compare match occurs.
Writing "010" If the RDA[2:0] bits are "010", a compare match occurs.
Writing "011" If the RDA[2:0] bits are "011", a compare match occurs.
Writing "100" If the RDA[2:0] bits are "100", a compare match occurs.
Writing "101" If the RDA[2:0] bits are "101", a compare match occurs.
Writing "110" If the RDA[2:0] bits are "110", a compare match occurs.
Writing "111" If the RDA[2:0] bits are "111", a compare match occurs.
bit0 Details
Writing "0" Disables the compare operation.
Writing "1" Enables the compare operation.
