MB95630H Series

444 FUJITSU SEMICONDUCTOR LIMITED MN702-00009-2v0-E

CHAPTER 21 MULTI-PULSE GENERATOR

21.6 Registers

[bit2] SEE2: SNI2 enable bit

This bit enables or disables the edge detection on the SNI2 pin.

Set this bit before setting the CMPE bit in the input control register (upper) (IPCUR) to "0".

[bit1] SEE1: SNI1 enable bit

This bit enables or disables the edge detection on the SNI1 pin.

Set this bit before setting the CMPE bit in the input control register (upper) (IPCUR) to "0".

[bit0] SEE0: SNI0 enable bit

This bit enables or disables the edge detection on the SNI0 pin.

Set this bit before setting the CMPE bit in the input control register (upper) (IPCUR) to "0".

bit2 Details

Writing "0" Disables the edge detection on the SNI2 pin.

Writing "1" Enables the edge detection on the SNI2 pin.

bit1 Details

Writing "0" Disables the edge detection on the SNI1 pin.

Writing "1" Enables the edge detection on the SNI1 pin.

bit0 Details

Writing "0" Disables the edge detection on the SNI0 pin.

Writing "1" Enables the edge detection on the SNI0 pin.
