Fujitsu 8FX User Manual

MB95630H Series
478 FUJITSU SEMICONDUCTOR LIMITED MN702-00009-2v0-E
CHAPTER 22 UART/SIO
22.7 Registers
[bit3:2] CBL[1:0]: Character bit length control bits
These bits select the character bit length.
The setting of these bits is valid in both clock asynchronous mode (UART) and clock synchronous mode
(SIO).
[bit1] CKS: Clock select bit
This bit selects a serial clock from the external clock or the UART/SIO dedicated baud rate generator.
Note: Setting this bit to "1" forcibly disables the output of the UCKn pin. The external clock cannot be used
in clock asynchronous mode (UART).
[bit0] MD: Operation mode select bit
This bit selects an operation mode from the clock asynchronous mode (UART) or the clock synchronous
mode (SIO).
Note:
During data transmission or reception, do not modify the settings of the UART/SIO serial
mode control register 1 ch. n (SMC1n).
bit3:2 Details
Writing "00" 5 bits
Writing "01" 6 bits
Writing "10" 7 bits
Writing "11" 8 bits
bit1 Details
Writing "0" UART/SIO dedicated baud rate generator
Writing "1" External clock
bit0 Details
Writing "0" Clock asynchronous mode (UART)
Writing "1" Clock synchronous mode (SIO)
