MX130 S2 Upgrade and Maintenance Manual 209
System board and components
I For detailed information on how to access the BIOS and modify
settings, refer to the "Description - BIOS Manual D3090 / D3091"
available online at http://manuals.ts.fujitsu.com or from the ServerView
Suite DVD 2 supplied with your PRIMERGY server.
Ê If BitLocker functionality is used and has been disabled before starting the
maintenance task, re-enable BitLocker as described in section "Enabling
BitLocker functionality" on page 66.
12.2.2 Removing the TPM board
V CAUTION!
Advise your contact persons that they must provide you with TPM
backup copies. For security reasons, the TPM must be restored/re-
saved by the customer. After installing a new system board, the TPM
must be enabled. You may not clear the TPM data.
If the contact persons DO NOT have a backup copy available, inform
them that replacing the TPM board will cause to lose all data.
12.2.2.1 Required tools
● Preliminary and concluding steps: tool-less
● Removing the system board:
– Phillips PH2 / (+) No. 2 screw driver
● Removing the TPM:
– thin slotted screw driver (
2 x 0.4 mm)
For the Japanese market:
– Dedicated TPM screw driver (CWZ8291A)
Field Replaceable Units (FRU)
Average task duration: 30 minutes
