MX130 S2 Upgrade and Maintenance Manual 227
Front panel and front USB
13.1.5 Removing the cable for On/Off button and HDD
activity LED
Figure 143: Disconnecting front panel cable
Ê Remove the cable from the cable holder(1).
Ê Disconnect the cable from system board connector Front panel (2).
/
