15 Appendix
15.1 Mechanical overview
15.1.1 Server front
Figure 157: PRIMERGY MX130 S2 front
Pos. Component
1 5.25-inch chassis bay
2 slimline ODD chassis bay
3 HDD activity indicator
4 Power-on indicator and On / Off button
5 Front USB connectors
/
