Fujitsu PRIMERGY MX130 S2 Upgrade and maintenance manua - Server Interior

MX130 S2 Upgrade and Maintenance Manual 247
Appendix
15.1.3 Server interior
Figure 159: PRIMERGY MX130 S2 interior
Pos. Component
1 System board D3090
2 Standard PSU
3 ON/OFF button, HDD activity indicator
4 Front USB
5 Drive bays
6System fan
7 HDD drive bay
8 CMOS battery
9 TPM board
10 Expansion card slots
11 Processor / CPU heat sink
12 Memory modules
/
