Fujitsu PRIMERGY RX1330 M5

Figure 201: Removing the COP (B)
▶
Pull the COP together with the front panel cable out of the opening.
Installing the COP
Figure 202: Installing the COP (A)
▶
Thread the front panel cable through the opening.
▶
Position the COP on the ear
.
Front panel
RX1330 M5 Upgrade and Maintenance Manual 261
